Codex CLI + GitHub Actions: The Complete Integration Guide

The openai/codex-action GitHub Action lets you run the Codex CLI inside any GitHub Actions workflow — gating PRs on AI-driven code review, auto-fixing failing CI, or running repeatable agentic tasks on every push.¹ This guide goes beyond the official quickstart: sandbox strategies, matrix parallelism, structured JSON output, Azure integration, cost attribution, and the full security model.

Architecture Overview

When the action runs, it:

Installs the Codex CLI at the pinned or latest version
Starts a Responses API proxy that forwards calls to OpenAI (or Azure) using the supplied key
Invokes codex exec with your prompt and flags under the chosen sandbox and privilege model
Emits the final Codex message as the final-message job output²

sequenceDiagram
    participant GHA as GitHub Actions Runner
    participant Action as openai/codex-action
    participant Proxy as Responses API Proxy
    participant OAI as OpenAI API
    participant CLI as codex exec

    GHA->>Action: trigger (push / PR / schedule)
    Action->>Action: install Codex CLI
    Action->>Proxy: start proxy with OPENAI_API_KEY
    Action->>CLI: codex exec --prompt "…" --sandbox workspace-write
    CLI->>Proxy: Responses API calls
    Proxy->>OAI: forward
    OAI-->>Proxy: model responses
    Proxy-->>CLI: relay
    CLI-->>Action: final message
    Action-->>GHA: outputs.final-message

The proxy is the key security boundary: the runner never holds a raw Authorization header in process environment — the action owns the key and the proxy forwards requests on behalf of the CLI.³

Input Reference

All inputs are optional except openai-api-key and one of prompt/prompt-file.⁴

Input	Purpose	Default
`openai-api-key`	Secret key for the Responses proxy	(required)
`prompt`	Inline task instructions	—
`prompt-file`	Path to a `.md` or `.txt` prompt in the repo	—
`codex-args`	Extra `codex exec` flags (JSON array or shell string)	`""`
`model`	Model override	System default
`effort`	Reasoning effort level (`minimal`→`xhigh`)	System default
`sandbox`	Execution mode	`""`
`safety-strategy`	Privilege reduction strategy	`drop-sudo`
`output-file`	Write final message to this path	—
`codex-version`	Pin a specific CLI release	latest
`codex-home`	Shared Codex config directory	`~/.codex`
`responses-api-endpoint`	Override API endpoint (Azure, proxy)	OpenAI default
`working-directory`	Run Codex from this directory	repo root
`allow-users`	Comma-separated GitHub usernames that may trigger	all collaborators
`allow-bots`	Allow GitHub bots to trigger	`false`

Store openai-api-key as a GitHub Actions secret; never hard-code it.⁵

Sandbox Modes

The sandbox input maps directly to codex exec --sandbox.⁶ Choose based on what the agent needs to do:

Mode	File access	Network	Use when
`read-only`	Read-only	Blocked	Code review, analysis, report generation
`workspace-write`	Read+write under repo root	Blocked	Auto-fix, scaffold, generate docs
`danger-full-access`	Unrestricted	Unrestricted	Workflows that run live servers, e2e tests

⚠️ danger-full-access with elevated runners gives the model broad access to the runner filesystem and network. Only use it in isolated, ephemeral environments.

Safety Strategies

Separate from the Codex sandbox, the safety-strategy input controls the OS-level privilege of the process running the CLI.⁷

flowchart TD
    A[Start] --> B{Platform?}
    B -- Linux/macOS --> C{Needs sudo later?}
    C -- Yes --> D[unprivileged-user]
    C -- No --> E[drop-sudo default]
    B -- Windows --> F[unsafe only]
    D --> G[Codex runs as codex-user account]
    E --> H[sudo revoked for remainder of job]
    F --> I[Full runner access]

drop-sudo (default) — Removes the current user from the sudo group before running Codex. Irreversible for the job: any subsequent step that needs sudo must run in a new job on a fresh runner.⁸
unprivileged-user — Use with codex-user input to run as a pre-created non-root account. Gives you more control on self-hosted runners.
read-only — Applies filesystem and network restrictions at the OS level in addition to Codex’s own sandbox. Most restrictive option.
unsafe — Required on Windows; no privilege reduction applied. ⚠️ Avoid on shared runners.

Core Patterns

1. PR Code Review Bot

Gate every opened PR with a structured Codex review:

name: Codex PR Review

on:
  pull_request:
    types: [opened, synchronize]

permissions:
  contents: read
  pull-requests: write

jobs:
  review:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v5
        with:
          fetch-depth: 0

      - name: Run Codex review
        id: review
        uses: openai/codex-action@v1
        with:
          openai-api-key: $
          prompt-file: .github/codex/prompts/pr-review.md
          sandbox: read-only
          safety-strategy: drop-sudo
          effort: medium
          output-file: review-output.md

      - name: Post review comment
        uses: peter-evans/create-or-update-comment@v4
        with:
          issue-number: $
          body-file: review-output.md

Store prompts in .github/codex/prompts/ so they are version-controlled alongside the workflow.⁹

2. Auto-Fix Failing CI

Trigger a Codex repair pass after a test run fails:

name: Codex Auto-Fix

on:
  workflow_run:
    workflows: ["CI"]
    types: [completed]

permissions:
  contents: write
  pull-requests: write

jobs:
  auto-fix:
    if: $
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v5
        with:
          ref: $
          fetch-depth: 0

      - uses: actions/setup-node@v4
        with:
          node-version: 22
          cache: npm

      - run: npm ci

      - name: Run Codex fix
        uses: openai/codex-action@v1
        with:
          openai-api-key: $
          prompt: |
            The CI workflow at $ failed.
            Identify the minimal change needed to make all tests pass.
            Implement only that change and stop.
          sandbox: workspace-write
          safety-strategy: drop-sudo
          effort: high

      - run: npm test

      - name: Open fix PR
        uses: peter-evans/create-pull-request@v6
        with:
          branch: codex/auto-fix-$
          title: "fix: Codex auto-repair for failing CI"
          body: "Automated fix generated by Codex. Review before merging."

The pattern follows: diagnose → fix → verify → propose — keeping humans in the loop via a draft PR.¹⁰

Matrix Builds for Parallel Agent Runs

GitHub Actions’ native matrix strategy lets you run independent Codex agents in parallel jobs sharing a single workflow. Use this to parallelise reviews, test-generation, or documentation tasks across services:

name: Parallel Codex Service Review

on:
  push:
    branches: [main]

jobs:
  review:
    strategy:
      matrix:
        service: [auth, payments, notifications, search]
      fail-fast: false
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v5

      - name: Review $
        id: codex
        uses: openai/codex-action@v1
        with:
          openai-api-key: $
          prompt: |
            Review the code in services/$/.
            Focus on security, error handling, and test coverage.
            Output a structured JSON report.
          codex-args: >-
            ["--output-schema-file", ".github/codex/schemas/review.json"]
          sandbox: read-only
          effort: medium
          output-file: review-$.json

      - name: Upload review
        uses: actions/upload-artifact@v4
        with:
          name: review-$
          path: review-$.json

Each matrix job runs as a separate runner, so four agents execute concurrently at the cost of four concurrent API calls.¹¹ Set fail-fast: false so one agent’s failure doesn’t cancel the others.

Aggregating Matrix Results

Use a follow-up needs job to combine the individual artefacts:

  aggregate:
    needs: review
    runs-on: ubuntu-latest
    steps:
      - uses: actions/download-artifact@v4
        with:
          pattern: review-*
          merge-multiple: true
          path: reviews/

      - name: Summarise with Codex
        uses: openai/codex-action@v1
        with:
          openai-api-key: $
          prompt: |
            Combine all JSON review files in ./reviews/ into a single
            executive summary markdown document.
          sandbox: workspace-write
          output-file: summary.md

flowchart LR
    subgraph Parallel ["Matrix Jobs (concurrent)"]
        A[auth agent]
        B[payments agent]
        C[notifications agent]
        D[search agent]
    end
    A -->|review-auth.json| E[Upload Artefacts]
    B -->|review-payments.json| E
    C -->|review-notifications.json| E
    D -->|review-search.json| E
    E --> F[Aggregate Job]
    F -->|summary.md| G[PR Comment / Notification]

Structured JSON Output

Pass --output-schema or --output-schema-file via codex-args to enforce a specific response shape.¹² This is the critical pattern for workflows that need to parse Codex output programmatically rather than displaying it as Markdown:

// .github/codex/schemas/review.json
{
  "type": "object",
  "required": ["severity", "issues", "recommendation"],
  "properties": {
    "severity": { "type": "string", "enum": ["low", "medium", "high", "critical"] },
    "issues": {
      "type": "array",
      "items": {
        "type": "object",
        "properties": {
          "file": { "type": "string" },
          "line": { "type": "integer" },
          "description": { "type": "string" }
        }
      }
    },
    "recommendation": { "type": "string" }
  }
}

- name: Structured security scan
  id: scan
  uses: openai/codex-action@v1
  with:
    openai-api-key: $
    prompt-file: .github/codex/prompts/security-scan.md
    codex-args: '["--output-schema-file", ".github/codex/schemas/review.json"]'
    sandbox: read-only

- name: Fail on critical findings
  run: |
    SEVERITY=$(echo '$' | jq -r '.severity')
    if [ "$SEVERITY" = "critical" ]; then
      echo "::error::Codex found critical security issue"
      exit 1
    fi

Structured output transforms Codex from a text generator into a programmable CI gate.¹³

Passing Artefacts Between Steps

The codex-home input lets you share MCP server configuration and local context between multiple action invocations in the same job:

jobs:
  staged-pipeline:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v5

      # Step 1: Plan
      - name: Generate implementation plan
        uses: openai/codex-action@v1
        with:
          openai-api-key: $
          prompt: "Analyse the failing tests and write a step-by-step implementation plan to PLAN.md"
          sandbox: workspace-write
          codex-home: /tmp/codex-shared
          effort: high

      # Step 2: Implement (reads PLAN.md written above)
      - name: Execute implementation
        uses: openai/codex-action@v1
        with:
          openai-api-key: $
          prompt: "Read PLAN.md and implement each step. Run tests after each step."
          sandbox: workspace-write
          codex-home: /tmp/codex-shared
          effort: high

Using codex-home ensures both steps share the same MCP server state and session context, which matters for long-horizon tasks split across multiple invocations.¹⁴

Azure OpenAI Integration

For teams using Azure-hosted models — common in regulated environments or for cost attribution against an Azure subscription — override the Responses endpoint:

- uses: openai/codex-action@v1
  with:
    openai-api-key: $
    responses-api-endpoint: https://YOUR_PROJECT.openai.azure.com/openai/v1/responses
    model: gpt-5.3-codex
    prompt-file: .github/codex/prompts/review.md
    sandbox: read-only

The proxy sends Authorization: Bearer <KEY> to the Azure endpoint.¹⁵ Azure API Management policies can intercept this for chargeback and audit logging per-workflow.

Cost Attribution in GitHub Actions Billing

Codex API costs are separate from GitHub Actions compute costs. Strategies to track them:

1. Per-workflow tags via prompt injection

Add a structured tag to every prompt:

prompt: |
  [workflow: pr-review] [repo: $] [run: $]
  Review the diff in this PR for correctness and security.

This appears in the OpenAI usage dashboard under the prompt content, allowing you to filter by tag.¹⁶

2. PostTaskComplete hook for logging

Set up a PostTaskComplete hook in .github/codex/config.toml within the workflow context that writes token usage to a file:

[hooks]
PostTaskComplete = [
  { cmd = "sh", args = ["-c", "echo '{\"run\":\"$GITHUB_RUN_ID\",\"tokens\":\"$CODEX_TOKEN_USAGE\"}' >> /tmp/cost-log.json"] }
]

Upload /tmp/cost-log.json as an artefact, then ingest it into your cost dashboard.

3. Separate API key per team

Use different OPENAI_API_KEY secrets scoped to different GitHub environments (staging, production) — OpenAI’s usage API breaks down usage per key.¹⁷

Branch Protection Integration

Require Codex review to pass before merging using status checks:

name: Codex Quality Gate

on:
  pull_request:

jobs:
  quality-gate:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v5

      - name: Codex quality scan
        id: scan
        uses: openai/codex-action@v1
        with:
          openai-api-key: $
          prompt: |
            Analyse the diff. Output ONLY the word "PASS" if the code meets
            quality standards, or "FAIL: <reason>" if it does not.
          sandbox: read-only
          effort: minimal

      - name: Enforce gate
        run: |
          RESULT="$"
          if [[ "$RESULT" != PASS* ]]; then
            echo "::error::Quality gate failed: $RESULT"
            exit 1
          fi

Add quality-gate as a required status check in your branch protection rules. The effort: minimal setting keeps latency and cost low for this high-frequency gate.¹⁸

Security Hardening Checklist

flowchart TD
    A[API Key] --> B[Store as GitHub Secret]
    B --> C{Repo visibility?}
    C -- Public --> D[Use GITHUB_TOKEN for PR scope, not write-all]
    C -- Private/Internal --> E[Restrict to specific environments]
    D --> F[Set allow-users to collaborators only]
    E --> F
    F --> G[Choose sandbox: read-only unless writes needed]
    G --> H[Use drop-sudo on Linux runners]
    H --> I[Pin codex-version to known-good release]
    I --> J[Review Codex diffs before merge - never auto-push to main]

Key rules:

Never set permissions: write-all — grant only the minimum (contents: write, pull-requests: write) needed.¹⁹
Pin codex-version to a specific release hash rather than latest in production workflows to prevent supply chain drift.
Always open a PR rather than pushing directly to main or master. Codex output is a proposal, not a mandate.
On public repositories, use allow-users to prevent external contributors from triggering expensive agentic workflows.
The drop-sudo side-effect (revoked sudo for the remainder of the job) means you cannot run package managers with sudo after the action fires — sequence your steps accordingly.

Practical Workflow Library

Store prompts as versioned files under .github/codex/prompts/. A recommended structure:

.github/
  codex/
    prompts/
      pr-review.md          # Standard PR review instructions
      security-scan.md      # Security-focused analysis
      test-generation.md    # Test scaffold prompts
      migration-check.md    # Breaking-change detection
    schemas/
      review.json           # Output schema for structured reviews
      migration.json        # Output schema for migration reports

This keeps prompts auditable, diffable, and reusable across workflows — the same prompt used in CI can be run locally with codex exec --prompt-file .github/codex/prompts/pr-review.md.²⁰

GitHub Agentic Workflows Context

GitHub’s February 2026 technical preview of intent-driven repository automation allows any compatible agent — including Codex — to receive natural-language instructions and generate complete GitHub Actions workflows from them.²¹ The longer-term direction: Codex as a first-class GitHub Actions participant, not just a workflow step. For now, openai/codex-action@v1 is the production path.

Citations

OpenAI. “GitHub Action – Codex.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “openai/codex-action.” GitHub. https://github.com/openai/codex-action ↩
OpenAI. “GitHub Action – Codex: Security.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “GitHub Action inputs reference.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
GitHub. “Encrypted secrets.” GitHub Docs. https://docs.github.com/en/actions/security-guides/encrypted-secrets ↩
OpenAI. “Sandbox modes.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “Safety strategy options.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “drop-sudo behaviour.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “Use Codex CLI to automatically fix CI failures.” OpenAI Cookbook. https://developers.openai.com/cookbook/examples/codex/autofix-github-actions ↩
OpenAI. “Auto-Fix CI Failures Cookbook.” OpenAI Cookbook. https://developers.openai.com/cookbook/examples/codex/autofix-github-actions ↩
GitHub. “Using a matrix for your jobs.” GitHub Docs. https://docs.github.com/en/actions/writing-workflows/choosing-what-your-workflow-does/running-variations-of-jobs-in-a-workflow ↩
OpenAI. “codex exec –output-schema.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “Structured output in Codex.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “codex-home input.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “Azure OpenAI integration.” OpenAI Developers. https://developers.openai.com/codex/github-action ↩
OpenAI. “Usage dashboard.” OpenAI Platform. https://platform.openai.com/usage ↩
OpenAI. “API keys and usage.” OpenAI Platform. https://platform.openai.com/api-keys ↩
GitHub. “About required status checks.” GitHub Docs. https://docs.github.com/en/repositories/configuring-branches-and-merges-in-your-repository/managing-protected-branches/about-protected-branches ↩
GitHub. “Automatic token authentication.” GitHub Docs. https://docs.github.com/en/actions/security-guides/automatic-token-authentication ↩
OpenAI. “codex exec.” OpenAI Developers. https://developers.openai.com/codex ↩
Tech Hub. “GitHub Introduces Agentic Workflows: Integrating AI Agents with GitHub Actions.” tech.hub.ms, February 2026. https://tech.hub.ms/2026-02-25-GitHub-Introduces-Agentic-Workflows-Integrating-AI-Agents-with-GitHub-Actions.html ↩
