Codex CLI Authentication: OAuth, Device Code, API Keys, and CI/CD Credential Management

Every Codex CLI session begins with authentication, yet the auth system is one of the least-documented corners of the toolchain. Codex supports three distinct sign-in methods — browser-based ChatGPT OAuth, device-code flow for headless environments, and API key authentication — each with different capabilities, billing models, and security trade-offs. This article maps the full authentication architecture: the OAuth PKCE flow internals, credential storage backends, token lifecycle management, CI/CD bootstrapping with CODEX_AUTH_JSON, managed environment lockdowns, and the dynamic bearer token system for custom model providers.

Two Billing Universes

Before choosing an auth method, understand that Codex CLI operates across two fundamentally different billing models ¹:

Method	Billing	Features
ChatGPT sign-in	Subscription (Plus $20, Pro $200, Business, Edu, Enterprise)	Full feature set: Codex cloud, fast mode, Codex-Spark, realtime voice
API key	Usage-based (per-token, standard API rates)	Core CLI only; no Codex cloud, no fast mode

ChatGPT sign-in is the default and recommended path for most developers. API key auth is suited to automation pipelines, custom harnesses, or teams that already manage OpenAI API spend through their platform account ¹.

Method 1: Browser-Based OAuth (Default)

Running codex login with no flags triggers the browser-based ChatGPT OAuth flow ¹. Under the hood, Codex:

Starts a local HTTP server on port 1455 to handle the callback ².
Generates a PKCE code verifier and challenge pair ².
Opens the browser to https://auth.openai.com/oauth/authorize with the public client ID app_EMoamEEZ73f0CkXaXp7hrann ³.
Exchanges the authorisation code for access and refresh tokens at https://auth.openai.com/oauth/token ³.
Persists the tokens using the configured credential storage backend.

sequenceDiagram
    participant CLI as Codex CLI
    participant Browser
    participant Auth as auth.openai.com

    CLI->>CLI: Generate PKCE verifier + challenge
    CLI->>CLI: Start localhost:1455 callback server
    CLI->>Browser: Open authorisation URL
    Browser->>Auth: User authenticates
    Auth->>Browser: Redirect with auth code
    Browser->>CLI: Callback to localhost:1455
    CLI->>Auth: Exchange code + verifier for tokens
    Auth->>CLI: Access token + refresh token
    CLI->>CLI: Persist to credential store

When Browser Auth Fails

The localhost callback requires the browser and CLI to run on the same machine. This breaks in common scenarios:

SSH sessions to remote development machines
Docker containers and Kubernetes pods
Corporate environments where localhost port binding is restricted
WSL2 instances where the default browser opens in Windows but the callback targets the Linux network namespace

For all of these, use device-code authentication instead ¹.

Method 2: Device Code Flow (Beta)

Device-code auth decouples the browser from the CLI, making it work in any headless or remote environment ¹:

codex login --device-auth

Or select “Sign in with Device Code” from the interactive login UI.

The flow presents a URL and a one-time code. Open the URL on any device (phone, laptop, different machine), authenticate, enter the code, and the CLI receives its tokens without needing a localhost callback ¹.

Prerequisites

Device-code login must be explicitly enabled before use ¹:

Personal accounts: Enable in ChatGPT → Settings → Security → “Allow device code login”
Workspace accounts: A workspace admin must enable it in ChatGPT → Workspace Settings → Permissions → “Allow device code login”

This opt-in requirement is a security measure — device-code flows are more susceptible to social engineering attacks than browser redirects, so OpenAI keeps them disabled by default.

Remote and Container Use Cases

For containerised development environments, the device-code flow is the standard pattern:

# Inside a Docker container or remote SSH session
codex login --device-auth

# Output:
# Open https://auth.openai.com/device in your browser
# Enter code: ABCD-1234
# Waiting for authentication...

For Codex running on Kubernetes, the app-server’s device-code sign-in support (added in late March 2026) enables authentication without browser callbacks — particularly useful for headless deployments ⁴.

Method 3: API Key Authentication

For automation and custom integrations, API key auth avoids the OAuth dance entirely ¹:

# Pipe from environment variable (recommended)
printenv OPENAI_API_KEY | codex login --with-api-key

# Or from a secrets manager
vault kv get -field=openai_key secret/codex | codex login --with-api-key

Never pass the API key as a command-line argument — it would appear in shell history and process listings. Always pipe via stdin ².

Feature Limitations

API key authentication provides access to the core CLI but excludes subscription-tier features ¹:

❌ Codex cloud (codex cloud exec)
❌ Fast mode (/fast)
❌ Codex-Spark (requires ChatGPT Pro)
❌ Realtime voice sessions
✅ Full local CLI functionality
✅ Custom model providers
✅ codex exec for CI/CD
✅ Multi-agent workflows (local)

Credential Storage Backends

Codex supports three credential storage modes, configured via cli_auth_credentials_store in config.toml ¹ ²:

# In ~/.codex/config.toml
cli_auth_credentials_store = "keyring"  # or "file" or "auto"

Mode	Storage Location	Encryption	Best For
`keyring`	OS credential manager (macOS Keychain, Windows Credential Manager, Linux Secret Service)	OS-managed	Shared machines, security-conscious setups
`file`	`~/.codex/auth.json` (plaintext)	None	CI/CD runners, containers, simple setups
`auto`	Prefers OS keyring, falls back to file	Mixed	Default; works everywhere

Keyring Isolation

Keyring entries use a computed key derived from the CODEX_HOME directory path, so different Codex installations (e.g., separate CODEX_HOME values for work and personal) maintain isolated credential stores ². On macOS, credentials appear in Keychain Access under the service name “Codex Auth”.

The `auth.json` File

When using file-based storage, auth.json sits in $CODEX_HOME (defaulting to ~/.codex). It contains access tokens, refresh tokens, and session metadata in plaintext JSON ¹:

# Inspect session health (without exposing tokens)
jq '{auth_mode, last_refresh, has_refresh_token: ((.tokens.refresh_token // "") != "")}' \
  ~/.codex/auth.json

⚠️ Treat auth.json as a password-equivalent secret. Never commit it, paste it into tickets, or share it in chat ¹.

Token Lifecycle and Refresh

For ChatGPT sessions, Codex manages token refresh automatically ¹:

Access tokens are refreshed proactively during active sessions before they expire.
If a token has expired (e.g., after an idle period), Codex performs a reactive refresh-and-retry on receiving a 401 response ⁵.
Sessions are considered stale after approximately 8 days without a refresh ⁵.
Refreshed credentials are written back to the storage backend, keeping auth.json current ⁵.

This means active Codex sessions can run indefinitely without re-authentication, but sessions left idle for more than ~8 days will require a fresh login.

CI/CD Authentication with `CODEX_AUTH_JSON`

Running Codex in CI/CD pipelines requires careful credential management. The recommended approach uses ChatGPT-managed auth with CODEX_AUTH_JSON as a bootstrap secret ⁵:

flowchart LR
    A[Trusted Machine] -->|codex login| B[auth.json created]
    B -->|Copy contents| C[GitHub Secret: CODEX_AUTH_JSON]
    C -->|First run only| D[Runner: seed auth.json]
    D -->|Codex auto-refreshes| E[Updated auth.json]
    E -->|Persisted on runner| F[Subsequent runs reuse]

GitHub Actions Setup

name: Codex CI
on: [push]

env:
  CODEX_HOME: $/.codex-home

jobs:
  codex-review:
    runs-on: self-hosted  # Persistent runner recommended
    steps:
      - uses: actions/checkout@v4

      - name: Bootstrap Codex auth
        env:
          CODEX_AUTH_JSON: $
        run: |
          mkdir -p "$CODEX_HOME"
          if [ ! -f "$CODEX_HOME/auth.json" ]; then
            printf '%s' "$CODEX_AUTH_JSON" > "$CODEX_HOME/auth.json"
            chmod 600 "$CODEX_HOME/auth.json"
          fi

      - name: Run Codex
        run: codex exec "review the changes in this PR"

Critical Detail: Conditional Seeding

The if [ ! -f ... ] guard is essential ⁵. Without it, every run overwrites the refreshed auth.json with the original (increasingly stale) secret, eventually causing auth failures.

Self-Hosted vs Ephemeral Runners

Runner Type	Strategy
Self-hosted	`CODEX_HOME` persists between jobs; `auth.json` refreshes naturally ⁵
Ephemeral (GitHub-hosted)	Restore `auth.json` from secure storage → run Codex → persist updated file back ⁵

For ephemeral runners, consider using a cache or artefact storage to persist the refreshed auth.json between runs, or simply use API key authentication to avoid the token-lifecycle complexity entirely.

Serialising Access

⚠️ Concurrent jobs sharing the same auth.json can cause race conditions during token refresh. Serialise Codex CI runs using GitHub Actions concurrency groups or a mutex ⁵:

concurrency:
  group: codex-auth-$
  cancel-in-progress: false

Managed Environment Controls

Enterprise administrators can lock down authentication behaviour using requirements.toml or workspace-level configuration ¹:

# Force ChatGPT-only login (no API keys)
forced_login_method = "chatgpt"

# Restrict to a specific workspace
forced_chatgpt_workspace_id = "ws_abc123def456"

These keys prevent developers from bypassing workspace audit trails by using personal API keys, and ensure all usage is billed through the organisation’s ChatGPT subscription ¹.

Codex cloud additionally requires multi-factor authentication (MFA) on the ChatGPT account before granting access ¹.

Custom Provider Authentication

For custom model providers (Ollama, Azure OpenAI, Mistral, LM Studio), Codex supports several auth patterns ⁶:

Static API Key via Environment Variable

[model_providers.azure]
name = "Azure OpenAI"
base_url = "https://my-resource.openai.azure.com/openai"
env_key = "AZURE_OPENAI_API_KEY"

Static HTTP Headers

[model_providers.custom]
env_http_headers = { "X-Custom-Auth" = "MY_AUTH_TOKEN_ENV" }

Dynamic Bearer Token Refresh

Added via PR #15917 (March 2026), custom providers can now fetch and refresh short-lived bearer tokens dynamically ⁴. This addresses enterprise identity providers that issue tokens with limited lifespans:

⚠️ The exact configuration keys for dynamic token refresh (auth_token_command, auth_token_refresh_interval_ms) were proposed in issue #15189 but the final implementation may use different key names ⁷. Check the latest configuration reference for current syntax.

Corporate Proxy and TLS Configuration

In environments with TLS-intercepting proxies, set the custom CA bundle before authentication ⁶:

# Codex-specific CA bundle
export CODEX_CA_CERTIFICATE=/etc/ssl/corporate-ca-bundle.pem

# Fallback (if CODEX_CA_CERTIFICATE is unset)
export SSL_CERT_FILE=/etc/ssl/corporate-ca-bundle.pem

codex login

This applies to login flows, Responses API connections, and WebSocket transports ⁶.

Logout and Credential Cleanup

# Clear all stored credentials
codex logout

Always use codex logout rather than manually deleting auth.json — the logout command clears credentials from all configured storage backends (file, keyring, or both) ².

When migrating between auth methods (e.g., ChatGPT to API key), run codex logout first to ensure no stale tokens interfere.

Troubleshooting

Symptom	Likely Cause	Fix
Login opens browser but callback fails	Port 1455 blocked or WSL network mismatch	Use `codex login --device-auth`
`401` errors after idle period	Session stale (>8 days)	Re-run `codex login`
Spark model not available	Using API key auth (not ChatGPT Pro)	Switch to ChatGPT sign-in
CI/CD auth fails intermittently	Concurrent token refresh race	Add `concurrency` group to workflow
Corporate proxy SSL errors	Missing custom CA bundle	Set `CODEX_CA_CERTIFICATE`

Codex generates a dedicated codex-login.log file for debugging authentication failures ¹. Check $CODEX_HOME/codex-login.log for detailed OAuth error messages.

Decision Matrix

flowchart TD
    A[Choose Auth Method] --> B{Environment?}
    B -->|Local desktop| C{Subscription?}
    C -->|ChatGPT Plus/Pro| D[Browser OAuth]
    C -->|API account only| E[API Key]
    B -->|Remote/SSH/Container| F[Device Code]
    B -->|CI/CD Pipeline| G{Billing preference?}
    G -->|Subscription| H[CODEX_AUTH_JSON bootstrap]
    G -->|Usage-based| I[API Key via env var]

    style D fill:#6f9,stroke:#333
    style E fill:#69f,stroke:#333
    style F fill:#f96,stroke:#333
    style H fill:#f9f,stroke:#333
    style I fill:#69f,stroke:#333

Citations

OpenAI, “Authentication — Codex Developer Docs,” 2026. https://developers.openai.com/codex/auth ↩ ↩² ↩³ ↩⁴ ↩⁵ ↩⁶ ↩⁷ ↩⁸ ↩⁹ ↩¹⁰ ↩¹¹ ↩¹² ↩¹³ ↩¹⁴ ↩¹⁵ ↩¹⁶ ↩¹⁷
Mintlify / OpenAI, “codex login — Codex CLI Reference,” 2026. https://www.mintlify.com/openai/codex/cli/login ↩ ↩² ↩³ ↩⁴ ↩⁵ ↩⁶
OpenAI, “Enable Headless or Command-line Authentication for Codex CLI — GitHub Issue #3820,” 2026. https://github.com/openai/codex/issues/3820 ↩ ↩²
OpenAI, “Changelog — Codex Developer Docs,” 2026. https://developers.openai.com/codex/changelog ↩ ↩²
OpenAI, “Maintain Codex account auth in CI/CD (advanced),” 2026. https://developers.openai.com/codex/auth/ci-cd-auth ↩ ↩² ↩³ ↩⁴ ↩⁵ ↩⁶ ↩⁷ ↩⁸
OpenAI, “Advanced Configuration — Codex Developer Docs,” 2026. https://developers.openai.com/codex/config-advanced ↩ ↩² ↩³
GitHub, “Support dynamic bearer token refresh for custom model providers — Issue #15189,” February 2026. https://github.com/openai/codex/issues/15189 ↩
