Codex TypeScript SDK: Streaming, Multimodal Inputs and Per-Thread Configuration
Codex TypeScript SDK: Streaming, Multimodal Inputs and Per-Thread Configuration
The Codex TypeScript SDK (@openai/codex-sdk) transforms Codex CLI from an interactive terminal tool into an embeddable agent runtime 1. It spawns the Rust-native CLI as a child process, communicating over JSONL via stdin/stdout 2, and exposes a clean async API for thread management, streaming events, multimodal inputs and structured output validation. This article covers the advanced features that make the SDK suitable for production agent orchestration, CI/CD integration and custom tooling.
Architecture and Installation
The SDK is a thin wrapper around the native Codex CLI binary. It does not re-implement the agent loop — it delegates entirely to the CLI process, injecting configuration as command-line flags and environment variables 1.
npm install @openai/codex-sdk
The runtime requirement is Node.js 18+ 2, though the Promptfoo integration documentation notes Node.js 20.20.0+ or 22.22.0+ for full compatibility 3.
graph LR
A[Your Application] -->|JSONL stdin/stdout| B[Codex CLI Process]
B -->|API Calls| C[OpenAI API]
B -->|Sandbox| D[Local Filesystem]
B -->|MCP| E[Tool Servers]
A -->|Thread Management| F["~/.codex/sessions/"]
Client Initialisation
The Codex class accepts global configuration that applies to all threads spawned from it:
import { Codex } from "@openai/codex-sdk";
const codex = new Codex({
apiKey: process.env.CODEX_API_KEY,
baseUrl: "https://api.openai.com/v1",
codexPathOverride: "/usr/local/bin/codex",
env: {
PATH: process.env.PATH,
HOME: process.env.HOME,
},
config: {
show_raw_agent_reasoning: true,
"sandbox_workspace_write.network_access": true,
},
});
The config object is flattened into dotted paths and serialised as TOML literals, then passed as repeated --config key=value flags to the CLI process 1. This means any configuration key supported by codex.toml is available programmatically.
Thread Management and Per-Thread Configuration
Threads are the SDK’s unit of conversation. Each thread maps to an independent CLI session with its own context, working directory and sandbox configuration 1.
Starting a Thread
const thread = codex.startThread({
workingDirectory: "/home/dev/my-project",
skipGitRepoCheck: false,
sandboxMode: "workspace-write",
model: "gpt-5.3-codex",
modelReasoningEffort: "medium",
networkAccessEnabled: true,
webSearchMode: "cached",
approvalPolicy: "on-request",
});
The sandboxMode parameter accepts three values: read-only for analysis-only tasks, workspace-write (the default) for standard development work, and danger-full-access for operations requiring unrestricted filesystem access 3. The modelReasoningEffort parameter controls how much compute the model spends on reasoning, with levels from minimal through to xhigh 3.
Thread Resumption
Sessions persist under ~/.codex/sessions/, enabling thread resumption across process restarts 1. Since v0.117.0, resumed threads also preserve the original model and reasoning effort settings 4:
// Resume a previous session
const thread = codex.resumeThread("thread_abc123");
const turn = await thread.run("Continue where we left off");
This is particularly useful for long-running CI pipelines or multi-stage workflows where context needs to survive process boundaries.
Multi-Turn Conversations
Reuse the same thread instance for sequential turns that share context:
const thread = codex.startThread({
workingDirectory: "/home/dev/api-server",
});
const diagnosis = await thread.run("Diagnose the failing integration tests");
console.log(diagnosis.finalResponse);
const fix = await thread.run("Implement the fix you identified");
console.log(fix.finalResponse);
Each turn builds on the conversation history of the thread, so the second prompt has full access to the diagnosis context without needing to repeat it.
Buffered Execution with run()
The run() method buffers all events internally and returns an aggregated result once the agent completes its turn 1:
const turn = await thread.run("Refactor the auth module to use JWT");
console.log(turn.finalResponse); // Agent's text response
console.log(turn.items); // Array of tool calls, file changes, etc.
console.log(turn.usage); // Token metrics
The usage object provides granular token accounting:
if (turn.usage) {
console.log(`Input: ${turn.usage.input_tokens}`);
console.log(`Cached: ${turn.usage.cached_input_tokens}`);
console.log(`Output: ${turn.usage.output_tokens}`);
}
Streaming with runStreamed()
For real-time progress feedback — essential for interactive UIs and monitoring dashboards — runStreamed() returns an async generator of typed events 12:
const { events } = await thread.runStreamed(
"Run the test suite and fix any failures"
);
for await (const event of events) {
switch (event.type) {
case "thread.started":
console.log("Thread initialised");
break;
case "turn.started":
console.log("Agent turn begun");
break;
case "item.started":
console.log("New item:", event.item?.type);
break;
case "item.updated":
// Incremental progress on current item
break;
case "item.completed":
console.log("Completed:", event.item);
break;
case "turn.completed":
console.log("Tokens used:", event.usage);
break;
case "turn.failed":
console.error("Turn failed:", event.error);
break;
case "error":
console.error("Stream error:", event.error);
break;
}
}
Event Types Reference
The streaming API emits the following event types 5:
| Event | Description |
|---|---|
thread.started |
Thread initialisation complete |
turn.started |
Agent begins processing the prompt |
item.started |
A new work item (command, file change, etc.) begins |
item.updated |
Incremental progress on the current item |
item.completed |
Work item finished — includes the completed item payload |
turn.completed |
Agent turn finished — includes usage token metrics |
turn.failed |
Turn terminated with an error |
error |
Stream-level error |
Item Types
Each completed item carries a type field indicating what the agent did 5:
agent_message— text response from the modelreasoning— internal chain-of-thought (whenshow_raw_agent_reasoningis enabled)command_execution— shell command with stdout, stderr and exit codefile_change— file modification with diffmcp_tool_call— MCP server tool invocationweb_search— web search query and resultstodo_list— internal task tracking
Multimodal Input: Text and Images
The SDK supports multimodal prompts by accepting an array of typed input entries instead of a plain string 12. Text entries are concatenated into the prompt, whilst image entries are passed to the CLI via --image flags:
const turn = await thread.run([
{ type: "text", text: "Review this UI mockup and identify accessibility issues" },
{ type: "local_image", path: "./designs/dashboard-v2.png" },
]);
console.log(turn.finalResponse);
Multiple images are supported in a single prompt:
const turn = await thread.run([
{ type: "text", text: "Compare these two screenshots and describe the visual differences" },
{ type: "local_image", path: "./before.png" },
{ type: "local_image", path: "./after.png" },
]);
Since v0.117.0, image workflows have been enhanced: the view_image tool returns image URLs in code mode, generated images are reopenable from the TUI, and image-generation history survives session resume 4. This means images produced during a thread persist across resumeThread() calls, making multi-session visual workflows viable.
sequenceDiagram
participant App as Your Application
participant SDK as Codex SDK
participant CLI as Codex CLI
participant API as OpenAI API
App->>SDK: thread.run([text, local_image])
SDK->>CLI: JSONL + --image flag
CLI->>API: Multimodal request
API-->>CLI: Response with image analysis
CLI-->>SDK: JSONL events
SDK-->>App: Turn result
Structured Output with JSON Schema
For programmatic consumption of agent responses, the outputSchema option constrains the model to produce valid JSON matching a provided schema 1:
const analysisSchema = {
type: "object",
properties: {
summary: { type: "string" },
risk_level: { type: "string", enum: ["low", "medium", "high", "critical"] },
affected_files: {
type: "array",
items: { type: "string" },
},
recommended_action: { type: "string" },
},
required: ["summary", "risk_level", "affected_files", "recommended_action"],
additionalProperties: false,
} as const;
const turn = await thread.run("Analyse the security implications of the latest PR", {
outputSchema: analysisSchema,
});
const analysis = JSON.parse(turn.finalResponse);
console.log(`Risk: ${analysis.risk_level}`);
Zod Integration
For TypeScript-first workflows, combine Zod schemas with zod-to-json-schema for type-safe structured output 1:
import { z } from "zod";
import { zodToJsonSchema } from "zod-to-json-schema";
const TestReport = z.object({
passed: z.number(),
failed: z.number(),
skipped: z.number(),
failures: z.array(z.object({
test: z.string(),
error: z.string(),
file: z.string(),
})),
});
const turn = await thread.run("Run the test suite and report results", {
outputSchema: zodToJsonSchema(TestReport, { target: "openAi" }),
});
const report = TestReport.parse(JSON.parse(turn.finalResponse));
Cancellation with AbortSignal
Long-running turns can be cancelled using the standard AbortController pattern 5:
const controller = new AbortController();
// Cancel after 60 seconds
setTimeout(() => controller.abort(), 60_000);
try {
const turn = await thread.run("Migrate the database schema", {
signal: controller.signal,
});
} catch (err) {
if (err.name === "AbortError") {
console.log("Turn cancelled due to timeout");
}
}
Practical Patterns
CI/CD Pipeline Integration
The SDK’s combination of structured output and per-thread configuration makes it well-suited for CI pipelines 1:
const codex = new Codex();
const thread = codex.startThread({
workingDirectory: process.env.GITHUB_WORKSPACE,
sandboxMode: "read-only",
model: "gpt-5.3-codex",
modelReasoningEffort: "high",
});
const review = await thread.run("Review the staged changes for bugs and security issues", {
outputSchema: reviewSchema,
});
const result = JSON.parse(review.finalResponse);
if (result.blocking_issues.length > 0) {
process.exit(1);
}
Streaming Progress to a Web UI
import { WebSocketServer } from "ws";
const wss = new WebSocketServer({ port: 8080 });
wss.on("connection", async (ws) => {
const thread = codex.startThread({
workingDirectory: "/app/project",
});
const { events } = await thread.runStreamed("Implement the feature from JIRA-1234");
for await (const event of events) {
ws.send(JSON.stringify({
type: event.type,
data: event.type === "item.completed" ? event.item : undefined,
usage: event.type === "turn.completed" ? event.usage : undefined,
}));
}
});
OpenTelemetry Observability
The Promptfoo integration demonstrates that streaming events can be captured as OpenTelemetry spans 3, enabling distributed tracing across your agent infrastructure. Enable this with the enable_streaming configuration when deep observability is required. ⚠️ Note that deep_tracing mode (which propagates OTEL context into the CLI itself) is incompatible with thread persistence 3.
Current Model Support
As of April 2026, the available models for the SDK are gpt-5.4, gpt-5.4-mini, gpt-5.3-codex and gpt-5.2, with ChatGPT Pro users also having access to gpt-5.3-codex-spark 6. The older gpt-5.2-codex, gpt-5.1-codex-mini and gpt-5.1-codex-max models are being removed from the model picker as of 7 April 2026, with full deprecation on 14 April 2026 6.
Summary
The Codex TypeScript SDK provides the programmatic surface needed to embed Codex agents into production systems. The key capabilities — per-thread configuration for isolation, runStreamed() for real-time feedback, multimodal inputs for visual workflows, structured output for machine-readable results, and session persistence for long-running pipelines — collectively make it possible to build sophisticated agent orchestration without reimplementing the agent loop.
