Multi-Agent v2 in Codex CLI: Path-Based Addressing, Structured Messaging, and the New Tool Surface

Codex CLI’s multi-agent system has undergone its most significant architectural revision since subagents first landed in v0.102.0. The multi-agent v2 feature, shipping across v0.118.0–v0.119.0 and refined in v0.120.0, replaces the parent-only communication model with path-based agent addressing, structured inter-agent messaging, and a richer tool surface that includes assign_task, send_message, and list_agents12. This article unpacks the v2 architecture, walks through the new tools, and shows how to migrate existing workflows.

Why v1 Hit a Ceiling

The original multi-agent model (v0.102.0+, enabled via multi_agent = true) gave Codex CLI parallel execution through spawn_agents_on_csv and the three built-in roles — default, worker, and explorer3. It worked well for embarrassingly parallel tasks like batch CSV audits, but had a hard structural limitation: sub-agents could only return results to their parent4. They could not message each other directly, could not receive steering instructions mid-execution, and had no addressable identity beyond an opaque internal thread ID.

This meant orchestration patterns like fan-out/fan-in with intermediate coordination, pipeline handoffs between specialist agents, or dynamic task reassignment were impossible without dropping out of Codex entirely and using external orchestration (the Agents SDK, Oh-My-Codex, or manual tmux wrangling).

Issue #12047 captured the community’s wishlist: named agents, per-agent configuration, async orchestration, @mention messaging, and teams as first-class units5. Multi-agent v2 delivers the foundational layer for most of these.

Enabling Multi-Agent v2

The v2 system sits behind a separate feature flag from the original multi_agent:

# ~/.codex/config.toml
[features]
multi_agent_v2 = true

This activates the v4 agent API internally, which introduces path-based addressing and the expanded tool surface6. The original multi_agent = true flag continues to work for v1 workflows — both can coexist during the transition period, though v2 tools supersede v1 equivalents when both are enabled.

Restart Codex after changing the flag, or use the features subcommand:

codex features enable multi_agent_v2

Path-Based Agent Addressing

The headline change in v2 is that every agent in a session receives a readable, hierarchical path address1. When you spawn an agent named security_reviewer from the root context, it receives the address /root/security_reviewer. If that agent in turn spawns a child called dependency_scanner, the child’s address becomes /root/security_reviewer/dependency_scanner.

graph TD
    Root["/root<br/>Orchestrator"] --> A["/root/frontend_worker<br/>Worker role"]
    Root --> B["/root/backend_worker<br/>Worker role"]
    Root --> C["/root/security_reviewer<br/>Explorer role"]
    C --> D["/root/security_reviewer/dep_scanner<br/>Worker role"]
    A -.->|send_message| B
    B -.->|send_message| A
    C -.->|assign_task| D

This addressing scheme provides three immediate benefits:

  1. Debuggability — TUI output tags every message with the source agent’s path, replacing the cryptic UUIDs of v15.
  2. Targeted messaging — any agent can route a message to any other agent by path, not just to its parent.
  3. Hierarchical scoping — policies and permissions can be applied at path prefixes (e.g., all agents under /root/security_reviewer/ inherit read-only sandbox mode).

The v2 Tool Surface

Multi-agent v2 exposes five tools to the model, replacing v1’s more limited spawn_agent/close_agent pair26:

spawn_agent

Creates a new child agent. In v2, the message parameter accepts a structured string (PR #16406)7 rather than requiring a separate instruction field:

spawn_agent(
  name: "api_reviewer",
  role: "explorer",
  message: "Review all REST endpoints in src/api/ for authentication gaps. Report findings as structured JSON.",
  fork_context: false
)

The fork_context parameter controls whether the child receives a snapshot of the parent’s conversation history8. Setting it to true is powerful but expensive — the child starts with full context including all prior tool calls. For most workflows, false (the default) is preferred, letting the child start fresh with only the spawning message as context. Enterprise teams can disable fork_context entirely via [agents] allow_fork_context = false8.

assign_task

Sends a task to an existing agent by path address (PR #16419)7. Unlike send_message, an assigned task carries an implicit expectation that the target will complete the work and report back:

assign_task(
  target: "/root/backend_worker",
  message: "Implement the caching layer for the /users endpoint based on the API reviewer's findings."
)

Tasks cannot be assigned to the root agent (PR #16424)7 — this prevents circular delegation where an orchestrator assigns work to itself.

send_message

Delivers a structured message to any agent by path (PR #16409)7. This is the mechanism for mid-execution steering, progress updates, and inter-agent coordination:

send_message(
  target: "/root/frontend_worker",
  message: "The backend API contract has changed: the /users response now includes a 'cached_at' timestamp field. Update your components accordingly."
)

The target agent receives the message as a high-priority event and processes it when it finishes its current tool call6. This is asynchronous but ordered — messages queue in delivery order.

list_agents

Returns the current agent tree with path addresses, roles, and status (active/idle/completed). Useful for orchestrators that need to make dynamic routing decisions:

list_agents()
→ /root (active, default)
  /root/frontend_worker (active, worker)
  /root/backend_worker (idle, worker)
  /root/security_reviewer (active, explorer)
    /root/security_reviewer/dep_scanner (completed, worker)

fork_context

Creates an independent execution context from the current conversation state (originally from v0.107.0’s /fork command)9. In v2, this is available as a programmatic tool, not just a slash command, enabling the model to decide when context forking would be beneficial.

Configuration: Roles and Constraints

The [agents] configuration block gains new relevance in v2. The max_threads and max_depth settings still apply3, but v2 adds spawn context metadata (PR #16746)7 that propagates the parent’s configuration to children:

# ~/.codex/config.toml
[agents]
max_threads = 6
max_depth = 2
allow_fork_context = true

[agents.security_reviewer]
description = "Reviews code for security vulnerabilities"
config_file = "~/.codex/agents/security-reviewer.toml"

[agents.fast_worker]
description = "Quick implementation tasks"
config_file = "~/.codex/agents/fast-worker.toml"

Custom agent TOML files can override model selection, reasoning effort, sandbox mode, MCP servers, and skills:

# ~/.codex/agents/security-reviewer.toml
name = "security_reviewer"
description = "Security-focused code reviewer with read-only access"
developer_instructions = """
You are a security reviewer. Analyse code for:
- Authentication and authorisation gaps
- Injection vulnerabilities
- Secrets in source code
- Dependency vulnerabilities
Report findings as structured JSON with severity, location, and recommendation fields.
"""
model = "gpt-5.4"
model_reasoning_effort = "high"
sandbox_mode = "read_only"

v1 → v2 Migration

For teams already using spawn_agents_on_csv for batch processing, the migration is straightforward — CSV batch workflows continue to work unchanged under v23. The key changes affect interactive orchestration:

Capability v1 v2
Agent identity Opaque thread ID Path address (/root/name)
Communication Child → parent only Any agent → any agent
Mid-execution steering Not supported send_message to running agents
Task delegation spawn_agent only spawn_agent + assign_task
Agent discovery Not available list_agents
Context forking /fork slash command fork_context tool

Practical Workflow: Feature Implementation Pipeline

Here’s a v2 workflow that demonstrates the new messaging capabilities — something impossible in v1:

sequenceDiagram
    participant O as /root (Orchestrator)
    participant E as /root/explorer
    participant W as /root/implementer
    participant R as /root/reviewer

    O->>E: spawn_agent("explorer", "Map the auth module structure")
    O->>W: spawn_agent("implementer", "Stand by for implementation task")
    E-->>O: Auth module report (3 files, 2 middleware, 1 config)
    O->>W: assign_task("Implement OAuth2 PKCE flow based on explorer findings")
    W-->>W: Implements changes across 3 files
    O->>R: spawn_agent("reviewer", "Review implementer's changes")
    R->>W: send_message("Line 47 in auth.ts has a timing vulnerability")
    W-->>W: Fixes the issue
    W-->>O: Implementation complete
    R-->>O: Review passed

The critical interaction is the reviewer sending a message directly to the implementer — in v1, this would have required the reviewer to report back to the orchestrator, which would then relay the message to the implementer, consuming context and adding latency.

What’s Still Missing

Multi-agent v2 is a substantial step forward, but the full vision from Issue #12047 remains partially unfulfilled5:

  • Teams as first-class units — the team.toml manifest and @teamname/agentname addressing are not yet implemented. Teams must be composed manually from individual agent spawns.
  • Async orchestration — the orchestrator still holds a context slot while waiting for children. True suspend-and-resume for idle orchestrators is not yet available.
  • @mention user syntax — users cannot yet type @agentname in the TUI input to route messages to specific agents. This requires TUI changes that are tracked but not shipped.
  • IDE integration — multi-agent v2 activity is surfaced only in the CLI TUI, not in the Codex App or VS Code extension4.
  • Subagent-specific notifications — the notification system (article #239) does not yet emit events for individual subagent completion, only aggregate session events.

The monitor role (long-running polling with up to 1-hour windows)4 is available but does not yet integrate with v2’s messaging — it cannot send structured progress updates to other agents.

Performance Considerations

Each spawned agent consumes its own model context and tool execution budget. The v2 messaging tools add token overhead for message routing metadata. For cost-sensitive workflows:

  • Use fork_context: false (the default) to avoid duplicating conversation history into children8
  • Keep max_depth at 1 or 2 — deep nesting multiplies context consumption exponentially
  • Prefer assign_task over send_message for discrete work units — it signals completion expectations to the model, reducing unnecessary status polling
  • Use the explorer role with a lighter model (e.g., gpt-5.4-mini) for read-only reconnaissance, reserving gpt-5.4 for implementation agents3

The Bigger Picture

Multi-agent v2 positions Codex CLI as a programmable orchestration runtime rather than just a single-agent coding assistant. The path-based addressing and structured messaging create a foundation for the team-based architectures the community has been requesting — and for integration with external orchestrators like the OpenAI Agents SDK, which can now address individual Codex agents by path when using Codex as an MCP server10.

For practitioners, the immediate win is clear: workflows that previously required external tooling (OMX, tmux scripts, Agents SDK wrappers) can now be expressed natively within Codex CLI’s multi-agent system. The /root/agent_a addressing makes debugging tractable, and send_message makes coordination possible without routing everything through the orchestrator.
