Codex CLI Custom Agent Definitions: Building Specialised Subagents with TOML Configuration

Codex CLI ships with three built-in agent types — default, worker, and explorer — but the real power emerges when you define your own 1. Custom agent definitions let you encode team-specific roles (reviewer, security auditor, documentation researcher, test writer) as standalone TOML files, each with its own model, sandbox policy, MCP servers, and behavioural instructions. This article is a practitioner’s reference for building, configuring, and orchestrating custom agents in Codex CLI v0.125.

Why Custom Agent Definitions Matter

The built-in agents are deliberately generic. A worker agent will happily write code, run tests, and explore the filesystem, but it has no opinion about how your team reviews pull requests or which MCP servers your documentation pipeline requires. Custom agents solve this by letting you:

  • Constrain scope — a read-only reviewer agent cannot accidentally modify files during code review 2.
  • Optimise cost — assign gpt-5.3-codex-spark to high-volume, low-complexity tasks whilst reserving gpt-5.5 for deep analysis 3.
  • Attach tooling — bind specific MCP servers to agents that need them, keeping the tool surface minimal for everyone else 1.
  • Standardise behaviour — developer_instructions act as per-agent system prompts, enforcing team conventions without polluting the root AGENTS.md 2.

File Layout and Discovery

Codex discovers custom agent definitions from two locations 1:

Scope Directory Use case
Personal ~/.codex/agents/ Cross-project agents (your personal reviewer, your preferred explorer)
Project .codex/agents/ Team-shared agents committed to version control

Each .toml file defines exactly one agent. The name field is the source of truth for identity — Codex matches on it when spawning — though matching the filename to the name is the recommended convention 1.

.codex/
├── config.toml
└── agents/
    ├── reviewer.toml
    ├── security-auditor.toml
    ├── test-writer.toml
    └── docs-researcher.toml

Project-scoped agent files only load when the project is trusted. Untrusted projects skip the .codex/ layer entirely, preventing supply-chain injection of malicious agent definitions 4.

Anatomy of a Custom Agent File

Every agent TOML file supports the following keys 1 5:

Required Fields

Key Type Purpose
name string Unique identifier used to spawn the agent
description string Guidance shown to Codex when choosing which agent to spawn
developer_instructions string Behavioural rules — the agent’s “system prompt”

Optional Fields

Key Type Default Purpose
model string parent model Override the model for this agent
model_reasoning_effort string parent setting "low", "medium", or "high"
sandbox_mode string parent policy "read-only", "workspace-write", or "danger-full-access"
nickname_candidates array of strings none Display names for spawned instances
mcp_servers table none Agent-specific MCP server bindings
skills.config table none Skill overrides for this agent

Practical Examples

Code Reviewer

A read-only reviewer that prioritises correctness, security, and test coverage:

name = "reviewer"
description = "PR reviewer focused on correctness, security, and missing tests."
model = "gpt-5.4"
model_reasoning_effort = "high"
sandbox_mode = "read-only"
nickname_candidates = ["Athena", "Ada"]

developer_instructions = """
Review code like an owner.
Prioritise correctness, security regressions, and test coverage gaps.
Lead with concrete findings including file paths and line numbers.
Never modify files — your job is analysis, not implementation.
If you find no issues, say so explicitly rather than inventing nitpicks.
"""

Security Auditor

A specialist that uses a vulnerability database MCP server:

name = "security_auditor"
description = "Scans code changes for security vulnerabilities and dependency risks."
model = "gpt-5.5"
model_reasoning_effort = "high"
sandbox_mode = "read-only"

developer_instructions = """
Focus exclusively on security concerns:
- Injection vulnerabilities (SQL, XSS, command injection)
- Authentication and authorisation flaws
- Secrets or credentials in code or configuration
- Dependency vulnerabilities via the security MCP server
- Insecure defaults and missing input validation

Rate each finding: CRITICAL, HIGH, MEDIUM, or LOW.
Include CWE identifiers where applicable.
"""

[mcp_servers.security-advisory]
command = "npx"
args = ["-y", "@security-tools/advisory-mcp-server"]

Lightweight Explorer

A fast, cheap agent for codebase reconnaissance:

name = "scout"
description = "Fast read-only explorer for tracing execution paths and gathering evidence."
model = "gpt-5.3-codex-spark"
model_reasoning_effort = "medium"
sandbox_mode = "read-only"

developer_instructions = """
Stay in exploration mode.
Trace execution paths, cite files and symbols with exact paths.
Prefer targeted search over broad directory scans.
Summarise findings concisely — the orchestrator will synthesise.
"""

Test Writer

An agent with write access, scoped to test files:

name = "test_writer"
description = "Generates and runs tests for specified modules."
model = "gpt-5.4"
model_reasoning_effort = "medium"
sandbox_mode = "workspace-write"

developer_instructions = """
Write tests for the specified module or function.
Follow existing test patterns in the repository.
Run tests after writing them to verify they pass.
Aim for edge cases and boundary conditions, not just happy paths.
Never modify production code — only test files.
"""

Registering Agents in config.toml

While Codex auto-discovers .toml files in the agents directory, you can also register agents explicitly in config.toml for additional metadata 5 6:

[agents]
max_threads = 6
max_depth = 1
job_max_runtime_seconds = 1800

[agents.reviewer]
description = "Find correctness, security, and test risks in code."
config_file = "./agents/reviewer.toml"
nickname_candidates = ["Athena", "Ada"]

[agents.security_auditor]
description = "Scan for vulnerabilities and dependency risks."
config_file = "./agents/security-auditor.toml"
nickname_candidates = ["Sentinel", "Shield"]

The config_file path resolves relative to the config.toml that declares it 6.

Orchestration Flow

Once custom agents are defined, you orchestrate them conversationally. The spawning, result collection, and thread management are handled by Codex’s runtime 1.

sequenceDiagram
    participant User
    participant Orchestrator as Codex (Root Session)
    participant Scout as scout agent
    participant Reviewer as reviewer agent
    participant Auditor as security_auditor agent

    User->>Orchestrator: "Review the changes in this PR"
    Orchestrator->>Scout: Spawn: trace affected code paths
    Orchestrator->>Reviewer: Spawn: review correctness and tests
    Orchestrator->>Auditor: Spawn: check for security issues
    Scout-->>Orchestrator: Execution paths and call graph
    Reviewer-->>Orchestrator: 3 findings (1 HIGH, 2 MEDIUM)
    Auditor-->>Orchestrator: 1 finding (SQL injection risk)
    Orchestrator->>User: Consolidated review with 4 findings

Key Orchestration Settings

Setting Default Impact
agents.max_threads 6 Maximum concurrent agent threads 6
agents.max_depth 1 Nesting depth — child agents can spawn, but grandchildren cannot by default 6
agents.job_max_runtime_seconds 1800 Timeout per worker in CSV batch jobs 6

Warning: Increasing max_depth beyond 1 risks exponential token consumption and latency spirals. Only do so for well-understood, bounded workflows 1.

Sandbox Inheritance and Overrides

Subagents inherit the parent session’s sandbox policy by default, but custom agents can override this explicitly 1. The runtime also reapplies the parent turn’s live overrides (approval modifications, sandbox choices) when spawning a child agent.

graph TD
    A[Root Session<br/>workspace-write] --> B[reviewer<br/>sandbox: read-only ✅]
    A --> C[test_writer<br/>sandbox: workspace-write ✅]
    A --> D[scout<br/>sandbox: read-only ✅]
    B -.->|"Cannot escalate<br/>beyond parent"| E[danger-full-access ❌]

    style E fill:#fee,stroke:#c00

A custom agent can restrict its own sandbox below the parent level (a reviewer declaring read-only under a workspace-write parent), but it cannot escalate beyond what the parent session permits 1.

CSV Batch Processing with Custom Agents

For repetitive tasks at scale, spawn_agents_on_csv processes one row per worker agent 1. This is experimental but powerful for tasks like batch migrations, multi-file reviews, or test generation across modules.

# In your prompt or automation script:
# "Use spawn_agents_on_csv with csv_path='modules.csv',
#  instruction='Write unit tests for the module at {path}',
#  id_column='module_name',
#  output_schema={\"tests_written\": \"number\", \"coverage\": \"string\"},
#  output_csv_path='results.csv'"

Each worker must call report_agent_job_result exactly once. Workers that exit without reporting are marked as errors in the output CSV 1.

Design Principles for Effective Custom Agents

Drawing from the official documentation and community patterns 1 7 8:

  1. Narrow scope — the best agents do one thing well. A “reviewer” that also fixes bugs will drift.
  2. Explicit completion criteria — include “done when” conditions in developer_instructions so the agent knows when to stop.
  3. Minimal tool surface — only attach the MCP servers an agent genuinely needs. Extra tools waste context tokens and invite off-task behaviour 9.
  4. Match model to task — use Spark for high-volume exploration, GPT-5.4 for balanced work, and GPT-5.5 for deep reasoning tasks 3.
  5. Read-only by default — unless an agent must write files, lock it to read-only. This prevents accidental side effects during analysis phases 2.

Inspecting Active Agents

During a session, use /agent in the TUI to switch between active agent threads 1. Approval requests from inactive threads surface with source labels, so you always know which agent is asking for permission.

Comparison with AGENTS.md Instructions

Custom agent definitions and AGENTS.md serve complementary purposes:

Aspect AGENTS.md Custom Agent TOML
Scope Project-wide rules and context Per-role behaviour and configuration
Loaded by All agents in the project Only the named agent
Can set model No Yes
Can set sandbox No Yes
Can bind MCP servers No Yes
Version controlled Yes Yes (project-scoped)

Use AGENTS.md for what the project is and custom agents for how each role operates within it 2 7.

Putting It All Together

A mature project structure might look like this:

my-project/
├── AGENTS.md                          # Project context, conventions, architecture
├── .codex/
│   ├── config.toml                    # Agent registry, max_threads, global settings
│   └── agents/
│       ├── reviewer.toml              # Code review specialist
│       ├── security-auditor.toml      # Security-focused analysis
│       ├── test-writer.toml           # Test generation and execution
│       ├── docs-researcher.toml       # Documentation lookup via MCP
│       └── scout.toml                 # Fast codebase exploration
└── .agents/
    └── skills/
        ├── review-checklist/SKILL.md  # Reusable review skill
        └── test-patterns/SKILL.md     # Testing patterns skill

This separation keeps project knowledge (AGENTS.md), runtime configuration (config.toml), role definitions (agents/), and reusable procedures (skills/) cleanly layered.
